TS-2669 RT Rough Terrain Scissor Lift

Self-Propelled Rough Terrain Scissor Lifts

The TS-2669 RT rough terrain scissor lift is a 26 ft engine-powered RT scissor lift designed for outdoor special working conditions such as difficult to pass, rugged, rocky, muddy, and rough use by workers. This is reflected in the fact that Made in China not only greatly reduces production and manufacturing costs, but also improves customer satisfaction and provides strong post-market support services, creating a favorable environment and support.

Key Specification

ModelMeasurementsMax. Working HeightMax. Platform HeightOverall WidthOverall Weight
TS2669RTUS32 ft26 ft5 ft7,500 lb
Metric10.00m8.00m1.75m3,600kg
Contact Us

TS-2669 RT Rough Terrain Scissor Lift Specification

MeasurementsUSMetric
Max. Working Height32 ft10.00m
Max. Platform Height26 ft8.00m
Overall Length(Without Outriggers)//
Overall Length(With Outriggers)14ft 9 in4.50m
Overall Width5 ft1.75 m
Overall Height(Rails Up)8 ft 6 in2.59m
Overall Height(Rails Down)6 ft 3.5 in1.92m
Platform Size(Length×Width) 9 ft 2 in x 5 ft 3 in2.79 m x 1.75 m
Platform Extension Size5 ft1.52m
Ground Clearance9.5in24cm
Wheelbase7 ft 6 in2.29m
Turning Radius0/7 ft 6in0/2.29m
(Inside/Outside)
Tyres26 x 12 in66 × 33 cm
WeightUSMetric
Overall Weight7,149 lb3,243 kg
Overall Weight(With outtriggers)7,500 lb3,600 kg
PerformanceUSMetric
S.W.L1,500 lb680 kg
S.W.L On Extension300 lb136 kg
Max. Occupants (in/out)4/44/4
Gradeability40%40%
Travel Speed(Stowed)3.5mph5.6km/h
Travel Speed(Raised)0.3mph0.5km/h
Max. Working Slope3°/2°3°/2°
Up/Down Speed34/31 sec34/31 sec
PowerUSMetric
Diesel EngineDuetz / CumminsDuetz / Cummins
Diesel Tank10 gal40 L
Hydraulic Tank (Hydraulic)18 gal 68 L

TS-2669 RT Rough Terrain Scissor Lift Features

  • To design and improve the condition in lower cost to be more competitive products.
  • To meet kinds of difficulty environments such as rugged, rocky, muddy, and roughs.
  • To lower production and manufacturing cost but performance improvement.
  • To be flexible optionally rough terrain & form filled tires wheels.
  • 26 ft vertical lifting ability, wide applications
  • Engine power RT scissor lift
  • Simple to move on uneven ground and sloped terrain
  • The biggest platform size in 26 ft lever makes more operators and tools to the job
TacMan Brochure EN All Right Reserved20230618Download

Related Product

Frequently Asked Questions

Q: What is a 26 ft rough terrain scissor lift and how does it work?

A: 26 ft rough terrain scissor lift is an outdoor sky-lift equipment. The working height is 26.00 – 32.00m and the lift capacity is 680kg. Besides, 26 ft rough terrain scissor lift has an extension deck to reach more.

Q: How high is a 2669 ft rough terrain scissor lift?

A: The 26 ft rough terrain scissor lift can be extended to 5 ft reach and the lifting capacity of between 1,350 lbs to 1,500 lbs.

Q: How much does a 2669 rough terrain scissor lift weigh?

A: The weight of a 26 ft rough terrain scissor lift is between 7,000 and 7,500 pounds. These units are built with an extremely compact design allowing it to fit into the smallest and tightest work areas.

Q: How wide is a 26 ft rough terrain scissor lift?

A: 26 ft rough terrain Scissor Lift, 5ft wide working designing with a working height of up to 32ft, this durable 32 ft.
